Small Coreless DC Motor

  • 28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB
  • 28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB
  • 28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB
  • 28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB
  • 28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB
28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB

28mm Brushless DC Coreless Motor – 54mm Type Model 2854RB

  • Model: 2854RB
  • 28mm brushless motor
  • Voltage: 6~26V
  • Brand:Kegu Motor
  • Product description: Due to 28mm micro brushless coreless motor's high energy conversion rate, small size, light weight and strong endurance, the 2854RB bldc coreless motor is suitable for variety of precision instruments
  • INQUIRY

28mm Brushless Coreless DC Motor, Model 2854RB series

1718 coreless motor

17mm coreless motor

Motor Name
2854RB
small brushless coreless motor

Typical Application
Medical equipment、
Home appliance、
Industrial automation
Nominal voltage
36V
No load current
530mA
Stall torque
401 mNm
Efficiency
77%

Induction of the High Torque 2854RB Series 28MM Brushless Coreless BLDC Motor


This type of 2854RB 28MM series Tattoo Equipment Coreless DC Motor will offer a good specification with high speed and torque to customer’s equipment and lead high precise, reliable control, lower vibration and noise on the tattoo Equipment which can offer the customer with good tattoo experience. We can make the customized shaft and holes at the front cover. Depending on the model, yet can nonetheless deliver the necessary performance – thanks to our high efficiency factors of up to 90 percent. Most of important, we can customize motor parameters for our customers which will give full play to product advantages.


Specification of the High Torque 2854RB Series 28MM Brushless Coreless DC Motor



Feature and Application of High Torque 28MM Series Coreless BLDC Motor



This 2854RB Series coreless motor is small ,light, precision, reliable control and delicately operate, which can offer high torque and speed for tattoo equipment and medical equipment.

Small vibration offering the best tattoo experience for customer.

Reliable and stable with long lifetime.

100% complete inspection of the materials after we get from our suppliers and products before ex-factory to ensure the quality for our customer.

The perfect substitute for European motors which can save lots of time and cost for our customer.



80% of coreless motors are customized. At present, the core key materials and components are still imported. KEGU MOTOR provide domestic customers to use international brand quality coreless motors with a higher performance, and continue to improve their product series . Prepare inventory according to plan, independently produce and process customized parts, so that the quality standards and process technology are consistent with the Swiss Maxon.

Take the market with technology and products
Deeply cultivating the industry, through years of hard work and accumulation, we have all kinds of coreless dc motor, which can be quickly mass-produced, and we have obtained a number of motor appearance patents and dozens of utility model patents. Become the domestic manufacturer with the largest shipment of large coreless motors above 4mm, the most complete model, the fastest delivery speed, and the most cost-effective manufacturer.
