Small 24mm Coreless DC Motor – 30mm Type Model 2430R

Small 24MM  Coreless DC Motor 2430R

Title:higher torque 2430R 24MM coreless motor brushed dc motor for tattoo machine, tattoo pen, eye massager

1.Certification: ISO9001, ROHS,etc.
2.Size: Dia 24 * L 30 mm
3.Rated Voltage: 3.0-24 V
4.No load speed : 8000-15570 rpm
5.No load current: 40-120 mA
6.Stall torque: 10.3-120.2 mNm

7. Application: Robots, RC servo motors, Small Injection Pump, etc.

Induction of the High Torque 2430R Model 24MM Coreless DC Motor

This type of 2430R series 24MM Brush Coreless DC Motor will offer a good specification with high speed and torque to customer’s equipment and lead high precise, reliable control, lower vibration and noise on the tattoo Equipment which can offer the customer with good tattoo experience. We can make the customized shaft and holes at the front cover. Depending on the model, yet can nonetheless deliver the necessary performance – thanks to our high efficiency factors of up to 90 percent. Most of important, we can customize motor parameters for our customers which will give full play to product advantages.

Specification of the High Torque 2430R Series 24MM Coreless DC Motor

Feature and Application of 2430R Motor 18mm 27mm 2607 motor 22mm 24mm Motor Coreless Brushed Brushless Planetary Gear Motor DC Geared Motor

This 2430R 24MM Series brush coreless motor is small ,light, precision, reliable control and delicately operate, which can offer high torque and speed for tattoo equipment and medical equipment.

Small vibration offering the best tattoo experience for customer.

Reliable and stable with long lifetime.

100% complete inspection of the materials after we get from our suppliers and products before ex-factory to ensure the quality for our customer.

The perfect substitute for European motors which can save lots of time and cost for our customer.

80% of coreless motors are customized. At present, the core key materials and components are still imported. KEGU MOTOR provide domestic customers to use international brand quality coreless motors with a higher performance, and continue to improve their product series . Prepare inventory according to plan, independently produce and process customized parts, so that the quality standards and process technology are consistent with the Swiss Maxon.
Take the market with technology and products
Deeply cultivating the industry, through years of hard work and accumulation, we have all kinds of coreless dc motor, which can be quickly mass-produced, and we have obtained a number of motor appearance patents and dozens of utility model patents. Become the domestic manufacturer with the largest shipment of large coreless motors above 4mm, the most complete model, the fastest delivery speed, and the most cost-effective manufacturer.
